SMS SM100 Sensor Auto Rod Changer

Step into the future of drilling with the SMS SM100, famously known as the SMS Auto Loader. As one of our trademark innovations, the SM100 is the system that revolutionized rod handling in the Indian drilling industry. Designed for heavy-duty truck-mounted rigs, this automated system eliminates manual labor, enhances operator safety, and slashes cycle times.

Precision Engineering & Heavy-Duty Build The SMS Auto Loader is built to withstand the rigors of deep waterwell applications. Every housing in the system is crafted from single-piece annealed casting, ensuring the structural rigidity needed to handle immense loads without fatigue.

• Massive Lifting Capacity: Effortlessly handles drill rods weighing up to 200 kg and lengths ranging from 4 to 6 meters.
• Steel Caster System: A heavy-duty steel caster rod changing mechanism ensures smooth, repeatable movement under the harshest site conditions.
• Large Deck Capacity: The specialized deck is designed to accommodate a massive 400 meters of drill pipes, allowing for deep-well operations without external support vehicles.

Advanced Automation & PLC Control The SM100 isn't just a mechanical arm; it’s a smart system.

• PLC-Driven Intelligence: The entire rod-changing sequence is managed by an advanced PLC system paired with high-precision Hydraulic Solenoid Valves for frame-perfect accuracy.
• Dual-Gripper System: Features two specialized Rod Gripper Cylinders and a dedicated arm to raise and lower 6.1-meter drill pipes with total stability.
• 0–90° Swing Option: Equipped with a precision swing function (0 to 90 degrees) for seamless coupling of drill rods directly to the drill head.
• Independent Feed Arm: A separate rod arm is provided to feed pipes from the rack to the changer, creating a fully hands-free workflow.

Product details

 Technical specification
