SMS T1 - Tractor Center PTO Pump Drive Gearbox

Get a Price/Quote

SMS T1 - Tractor Center PTO Pump Drive Gearbox Specification

Spare Part Support
10 years

Driveline
Double bearing housing

PTO Drive
Center joint

Pump Mounting
Front 2/Rear 2

Application
Domestic Waterwells

Bearings
Full casted 4-bearing

Gear Oil Grade
ISO VG-150

Gearbox Ratio
1:1.15, 1:1.5

Pump Capacity
5-55 GPM

Drive Type
Heavy duty

Gearbox Weight
100 Kg

Max Pressure
2500 PSI

Housing Material
Cast iron

Max No. Of Pumps
2-4

About SMS T1 - Tractor Center PTO Pump Drive Gearbox

SMS T1- Tractor Center PTO Pump Drive Gearbox

Our SMS T1 Tractor Center PTO is a 4 Pump Pump drive Gearbox is a well renowned PTO gearbox all over drilling industry in India, with Impeccable efficiency, With breaking a record of >30000 hours of working. With easy to service. SMS PTO can drive 2-4 hydraulic pump units ranging from 6 Gpm to 55 Gpm Hydraulic pumps of any mounting standards. With sleek design housing is reduced to 5% from its old housing design, It has a smooth power transfer from tractor engine to the PTO gearbox.

Product details

Application	Domestic Waterwells
Max Tractor Power	80-180 HP
Max Number of Pumps	2- 4 Pumps
Pump Capacity	5-55 GPM
Pump Position	Front 2/ Rear 2
Gearbox Housing	MS Annealed, Graded CI (In House)
Center Bearing	Full Casted 4 Bearing Double Bearing Housing Driveline- Heavy Duty
Warranty	3 Year Warranty, 10 year Spare part backup

Technical specifiation

Drive	Tractor Center PTO Joint
Shifting	-None-
Gearbox Ratio	1:1.15, 1:1.5
Max Input RPM	2000 RPM
Max Input Torque	2500 Nm
Max Pressure to Pump	upto 2500 PSI
Gearbox Weight	100 Kg's without Motor
Gear Oil	ISO VG-150
