SMS S2-Deck Engine PTO Gearbox

Get a Price/Quote

Product Details:

Click to view more
Share Your Product:

Request To Call Back Send Inquiry

Product Description

SMS S2- Deck Engine PTO Gearbox

Our SMS S2 Deck Engine PTO Gearbox is a 4 Pump drive Gearbox is a well renowned PTO gearbox all over drilling industry in India specially made for Deck Engines ranging from 180- 500 HP, with Impeccable efficiency, With breaking a record of >30000 hours of working. With easy to service. SMS S2 PTO can drive 2-4 hydraulic pump units ranging from 6 Gpm to 65 Gpm Hydraulic pumps of any mounting standards. With sleek design housing is reduced to 5% from its old design, It has a smooth power transfer from tractor engine to the PTO gearbox.

Product details

Application	Water well/ Marine/ Core Drilling
Max Truck Power	180-500 Hp
Max Number of Pumps	2-4 Pumps
Warranty	1 Year Warranty, 10 year Spare part backup
Pump Capacity	6-65 GPM
Pump position	Front 2/ Rear 2
Gearbox Housing	MS Annealed, Graded CI (In House)
Center Bearing	Full Casted 4 Bearing Double Bearing Housing Driveline- Heavy Duty

Technical Specification

Drive	Direct Connection from Engine Flywheel
Shiting	None
Gearbox Ratio	1:1.15, 1:1.5
Max Input RPM	2000 RPM
Max Input Torque	5000 Nm
Max Pressure to pump	upto 3000 PSI
Gearbox Weight	125 Kg's Without Pumps
Gear oil	ISO VG-150
