SMS T2-Tractor Pump Drive Gearbox

Name: SMS T2-Tractor Pump Drive Gearbox
Brand: SMS Gears

Get a Price/Quote

MOQ : 1 Piece

SMS T2-Tractor Pump Drive Gearbox Specification

Direction
Opposite to Engine Shaft

Output Torque
High Torque Output

Rated Power
280 HP

Input Speed
2000 RPM

Output Speed
4200 RPM

Efficiency
Approx. 95%

Lubrication Type
Splash Lubricated

Max Input RPM
2000 RPM

Required Oil
MOBIL ISO VG-150

Casing Material
Cast Iron

Gearbox Weight
120 kgs

Paint Finish
Industrial grade

Pump Mounting
Front 4 pumps

Application
Domestic Waterwells

Ratio
1:2.1

Mounting Type
Flange Mounted

Sealing Type
Oil Sealed

Gearbox Connection
Tractor PTO Shaft

Max Input HP
280 HP

SMS T2-Tractor Pump Drive Gearbox Trade Information

Minimum Order Quantity
1 Piece

Supply Ability
100 Pieces Per Month

Delivery Time
7 Days

About SMS T2-Tractor Pump Drive Gearbox

SMS T2- Tractor Pump Drive Gearbox

Our SMS Tractor 4 Bore 4 Pump drive Gearbox is a well renowned PTO gearbox all over drilling industry in India, with Impeccable efficiency, With breaking a record of >30000 hours of working. With easy to service. SMS PTO can drive 2-4 hydraulic pump units that can be mounted directly on the front side of the tractor PTO Shaft. Pump capacity ranging from 6 Gpm to 55 Gpm Hydraulic pumps of any mounting standards. With sleek design housing is reduced to 5% from its old housing design, It has a smooth power transfer from tractor engine to the PTO gearbox.

Prdocut details

Application	Domestic Waterwells
Gearbox Connection	Tractor PTO Shaft
Sense of Rotation	Opposite to Engine Shaft
Pump Mounting Method	Front 4 pumps
Gearbox Weight	120 Kg's
